299D3

Engine Model .................... Caterpillar C3.8 DIT
Engine Type .................... 4-cycle liquid cooled diesel
Number of Cylinders .................... 4, in-line
Displacement, cu.in (L) .................... 231.9 (3.80)
Cylinder Bore, in (mm) .................... 3.94 (100.0)
Piston Stroke, in (mm) .................... 4.72 (120.0)
Aspiration .................... Turbocharged
Rated Engine Power, hp (kW) .................... 95.0 (71.0)
Maximum Engine Power, hp (kW) .................... 98.0 (73.0)
Rated Engine Speed, rpm .................... 2400
Compression Ratio .................... 17:1
Firing Order .................... 1-3-4-2
Fuel System .................... Direct Injection
Air Cleaner .................... Dual element, radial seal
Emission Level .................... Tier 4 Interim
Fuel Tank Capacity, gal (L) .................... 31.7 (120.0)
Oil Capacity, qts (L) .................... 13.8 (13.0)

OPERATINGS SPECS

Operating Specifications

Rated Operating Capacities - 35%

Tipping Load 3480 lb

Tipping Load 9945 lb

Breakout Force - Tilt Cylinder 7270 lb

Breakout Force - Lift Cylinder6162 lb

Rated Operating Capacity with Optional Counterweight 5240 lb

Ground Contact Area - With 400 mm/15.7 in Track 2184 in²Ground Pressure - With 400 mm/15.7 in Track5.3 psi

Note

Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, two speed, 2036 mm (80 in) low profile bucket, 400 mm (15.7 in) tracks, dual flange front idler/single flange rear idler, standard flow hydraulics, enclosed cab with glass door, side windows, heater, mechanical suspension seat, advanced display, 850 CCA battery, no optional counterweights and manual quick coupler (unless otherwise noted).Rated Operating Capacities - 50% Tipping Load 4970 lb Ground Contact Area - With 450 mm/17.7 in Track 2463 in²Ground Pressure - With 450 mm/17.7 in Track 4.7 psi
